Lattice LC4256V-75TN176C復雜可編程邏輯器件(CPLD)
發布時間：2024-09-11 09:25:56 瀏覽：1346
Lattice半導體公司推出的LC4256V-75TN176C是一款高性能的復雜可編程邏輯器件(CPLD)，屬于ispMACH
4000V/B家族，符合RoHS標準，確保環境友好。該產品設計精良，旨在滿足現代工業控制和通信系統對性能和可靠性的高要求。
系統屬性
該CPLD包含16個邏輯模塊，提供4個全局時鐘和2個I/O Bank。其程序存儲類型為EEPROM，內置防振器，確保數據的安全性和穩定性。
軟/硬件規格
LC4256V-75TN176C擁有256個論壇宏DB包含數，80個宏單元和576個寄存器。最大用戶I/O數達到128，支持在線系統編程和可重編程性。其最大頻率為168
MHz，最大時鐘到輸出延遲為4.5 ns，最大地傳送延遲為7.5 ns，速度等級為75，且受時間抖動控制。
電氣參數
該產品支持的最大工作電源電壓為3.6 V，最小為3 V，額定工作電源電壓為3.3 V。靜態功耗電值為5 mA，最大工作重點電流為12.5
mA。
環境/機械特性
LC4256V-75TN176C的最低工作溫度為0℃，最高工作溫度為90℃，適應多種環境條件。
包裝信息
該CPLD采用商業供應鏈，封裝形式為托盤，商名為ispMACH 4000。安裝方式為表面焊裝，包裝尺寸為寬度14 mm，高度2.4 mm，長度24
mm。引線數目為176，PCB散熱采用QFP塑，封裝驗證為T(mén)QFP驗證，引腳數為176，引線形狀為扁平型。
LC4256V-75TN176C
CPLD以其卓越的性能和可靠性，成為工業控制和通信系統等領域的理想選擇。其靈活的編程能力和穩定的運行特性，確保了系統的高效運行和長期穩定性。
